Tools Registry

The Tools Registry is a small Flask + MongoDB service that stores tool definitions (ToolEntry records) and the download link for each tool's code. Agents read from it through the Tools SDK; developers publish to it by uploading a bundle (see Creating a Tool).

What it does

• Accepts a tool bundle, uploads the code to the assets server, and stores the entry in MongoDB
• Gets, updates, and deletes tools by tool_id
• Filters tools by type, tag, keyword, execution mode, or policy URI, or with a raw MongoDB query

All tools live in a single MongoDB collection, tools_registry.tools, keyed by tool_id.

---

Running the service

Setting	Value
Port	6000
MONGO_URL	MongoDB connection string (required)
ASSETS_SERVER_URL	Assets server that stores tool.zip. The registry calls POST {ASSETS_SERVER_URL}/upload and expects {"url": ...} back.

cd functions-tools/src/tools/registry
docker build -t tools-registry .
docker run -p 6000:6000 \
  -e MONGO_URL="mongodb://mongo:27017" \
  -e ASSETS_SERVER_URL="http://assets:8080" \
  tools-registry

Or run it directly with pip install -r requirements.txt && python main.py.

---

Schema

@dataclass
class ToolEntry:
    tool_id: str = ''
    tool_metadata: Dict[str, Any] = field(default_factory=dict)
    tool_search_description: str = ''
    tool_tags: List[str] = field(default_factory=list)
    tool_type: str = ''
    tool_man_page_doc: str = ''
    tool_api_spec: Dict[str, Any] = field(default_factory=dict)
    tool_custom_actions_dsl_map: Dict[str, Any] = field(default_factory=dict)
    default_tool_usage_credentials: Dict[str, Any] = field(default_factory=dict)
    tool_settings: Dict[str, Any] = field(default_factory=dict)
    tool_parameters: Dict[str, Any] = field(default_factory=dict)

    tool_execution_mode: str = ''
    tool_policy_rule_uri: str = ''
    tool_source_code_link: str = ''
    tool_runtime_type: str = ''
    tool_service_url: str = ''
    tool_system_function_rpc_id: str = ''
    tool_validation_policy_rule_uri: str = ''
    tool_validation_mode: str = ''

The second column shows how the current SDK uses each field: Runtime means agents_tools reads it to load or execute the tool, Search means LLM-based search reads it, and Stored means the field is saved and queryable but not used by the SDK.

Field	Used by	Description
tool_id	Runtime	Unique ID (primary key).
tool_runtime_type	Runtime	"python" or "" → Python executor; anything else → binary executor.
tool_source_code_link	Runtime	URL of the code archive. Set by the registry on upload.
tool_parameters	Runtime	Default configuration passed to the tool. Merged with overrides from AgentTools.add().
tool_api_spec	Search	Input/output contract. LLM search reads tool_api_spec.entrypoints.execute.input (a JSON Schema).
tool_search_description	Search	Short description; also used by the by-keyword query.
tool_tags	Search	Tags for filtering and LLM search.
tool_man_page_doc	Stored	Markdown docs. Set by the registry from tool.md.
tool_metadata	Stored	Free-form metadata (author, version, license, …).
tool_type	Stored	Category, e.g. text-processing, utility.
tool_settings	Stored	Free-form settings.
default_tool_usage_credentials	Stored	Credentials the tool needs. Prefer putting secrets in tool_parameters overrides at add() time rather than in the registry.
tool_custom_actions_dsl_map	Stored	Optional DSL map for custom actions.
tool_execution_mode	Stored	e.g. sync, async.
tool_policy_rule_uri	Stored	Policy governing usage.
tool_service_url	Stored	URL of a hosted service, if any.
tool_system_function_rpc_id	Stored	ID of a system (gRPC) tool, see RPC System.
tool_validation_policy_rule_uri	Stored	Validation policy URI.
tool_validation_mode	Stored	e.g. strict, loose.

---

API reference

Set REG=http://<tools-registry>:6000 in the examples below.

Method	Path	Purpose
POST	/tools/upload	Register a tool from a bundle
GET	/tools/<tool_id>	Get a tool
PUT	/tools/<tool_id>	Update fields
DELETE	/tools/<tool_id>	Delete a tool
GET	/tools/query/by-type?type=	Filter by tool_type
GET	/tools/query/by-tag?tag=	Filter by a tag
GET	/tools/query/by-keyword?keyword=	Case-insensitive regex on tool_search_description
GET	/tools/query/by-execution-mode?mode=	Filter by tool_execution_mode
GET	/tools/query/by-policy-uri?uri=	Filter by tool_policy_rule_uri
POST	/tools/query/generic	Raw MongoDB filter

POST /tools/upload

Upload a zip containing spec.json, tool.zip, and tool.md at its root. The registry:

1. Reads spec.json (it must contain tool_id)
2. Uploads tool.zip to the assets server and sets tool_source_code_link
3. Sets tool_man_page_doc from tool.md
4. Inserts the entry

curl -X POST $REG/tools/upload -F "file=@text-stats-bundle.zip"

Status	Body
200	{"message": "Tool uploaded successfully", "tool_id": "text-stats"}
400	{"error": "Missing file part"} or {"error": "No selected file"}
500	{"error": "Failed to process tool package"}: a file is missing, tool_id is missing, the asset upload failed, or the tool_id already exists

GET /tools/<tool_id>

curl $REG/tools/text-stats

Returns the full ToolEntry (200) or {"error": "Tool not found"} (404).

PUT /tools/<tool_id>

Sets the given top-level fields (MongoDB $set). Use dotted keys to update a nested field.

curl -X PUT $REG/tools/text-stats \
  -H "Content-Type: application/json" \
  -d '{"tool_tags": ["text", "nlp"], "tool_parameters.top_n": 5}'

Returns {"message": "Tool updated successfully"} (200), {"error": "Missing update payload"} (400), or {"error": "Tool not found"} (404).

DELETE /tools/<tool_id>

curl -X DELETE $REG/tools/text-stats

Returns {"message": "Tool deleted successfully"} (200) or {"error": "Tool not found"} (404).

Query endpoints

All return a JSON array of ToolEntry objects (an empty array if nothing matches).

curl "$REG/tools/query/by-type?type=text-processing"
curl "$REG/tools/query/by-tag?tag=nlp"
curl "$REG/tools/query/by-keyword?keyword=word"
curl "$REG/tools/query/by-execution-mode?mode=sync"
curl "$REG/tools/query/by-policy-uri?uri=policies://validate/compliance"

POST /tools/query/generic

The body is passed directly to MongoDB find().

# all python tools tagged nlp or text
curl -X POST $REG/tools/query/generic \
  -H "Content-Type: application/json" \
  -d '{"tool_runtime_type": "python", "tool_tags": {"$in": ["nlp", "text"]}}'

# list every tool
curl -X POST $REG/tools/query/generic -H "Content-Type: application/json" -d '{}'

Warning

This endpoint accepts any MongoDB filter. Restrict it to trusted callers.

---

Notes

• GraphQL: a GraphQL schema exists in core/ql.py, but the /graphql route is disabled in the current build. Use /tools/query/generic instead.
• No list endpoint: there is no GET /tools. Use POST /tools/query/generic with {}.
• System tools (gRPC tools running on cluster nodes) are tracked by a separate service. See RPC System.
